Description

Toa WS-5325H UHF Wireless Set Price in Bangladesh

The WS-5325H includes a wireless transmitter WM-5325, a headset microphone WH-4000H, and a diversity wireless tuner WT-5810. The WM-5325 wireless transmitter has been manufactured for use with a UHF system. Thanks to the PLL-synthesizer system, 64 different operating frequencies are made available. A high output power ensures stable radio signal transmission. The WH-4000H employs an electret condenser microphone element and has been designed for use in speech reinforcement applications. The WT-5810 is a PLL-synthesizer-controlled double superheterodyne diversity tuner designed to be used with a UHF wireless system. It employs a compander noise reduction circuit to minimize the influence of ambient RF noise

Trimatrik has an available WS-5325H that includes a wireless transmitter of different brands with the best market price for the Dealer or retail customers. Trimatrik is a Bangladesh-based supplier of PA System Any Model Price in Bangladesh. The company offers a variety of goods, such as access control systems, Surveillance cameras, and EAS Security Alarm System IP Cameras. Trimatrik has been in business Since 2009 and has a reputation for quality products and excellent customer service. You can buy from our head office (Dhaka, Uttara). We have dedicated Technical engineers to assist all over Bangladesh. The best pricing can be guaranteed for complete setup and post-purchase assistance. To know more details visit our website please Contact us at our Facebook Page or 0185-3330338, 0185-3330344

WS-5325H wireless transmitter specification:

PRODUCT COMPOSITION	Wireless transmitter WM-5325 …1, Headset microphone WH-4000H, …1, Diversity wireless tuner WT-5810 …1
FREQUENCY RANGE	576 – 865 MHz (*1), UHF
TONE FREQUENCY	32.768 kHz
OPERATING TEMPERATURE	-10 ℃ to +50 ℃ (14 ゜F to 122 ゜F)
ACCESSORY	AC adapter (*2) …1, Screwdriver …1, Storage case …1, Neck strap …1

Wireless transmitter

(*3) 0 dB = 1 V

MODULATION	Frequency modulation
CHANNEL SELECTABLE	64 channels (the number of channels may differ from country to country)
RF CARRIER POWER	Less than 50 mW (Factory preset 10 mW ERP)
OSCILLATOR	PLL synthesized
MAXIMUM INPUT LEVEL	-14 dB to -29 dB (*3) (Audio level control: Min. to Max.)
BATTERY	WB-2000 (WB-2000-2 contains 2 pieces) rechargeable battery (option) or AA alkaline dry cell battery
BATTERY LIFE	Approx. 13 h (when the WB-2000 rechargeable battery is used) Approx. 10 h (when the alkaline battery is used)
INDICATOR	Power/Battery lamps
ANTENNA	Built-in type
FINISH	Resin, coating
DIMENSIONS	62 (W) × 102.5 (H) × 23 (D) mm (2.44 × 4.04″ × 0.91″)
WEIGHT	90 g (0.2 lb) (with battery)

Headset microphone

(*3) 0 dB = 1 V

MICROPHONE ELEMENT	Electret condenser type: Unidirectional
SENSITIVITY	-66 dB ±3 dB (0 dB = 1 V/0.1 Pa, 1 kHz)
CORD LENGTH	1.3 m (4.27 ft)
FINISH	Frame: Stainless, black (silicon rubber), Gooseneck: Black (shrink tube)
WEIGHT	50 g (0.11 lb) (cable included)

Diversity wireless tuner

(*3) 0 dB = 1 V

POWER SOURCE	AC mains (supplied AC adapter must be used)
POWER CONSUMPTION	130 mA (12 V DC)
CHANNEL SELECTABLE	16 channels
RECEIVING SYSTEM	Double super-heterodyne
DIVERSITY SYSTEM	Space diversity
MIXING OUTPUT	MIC: -60 dB (3), 600 Ω, balanced, XLR-3-32 type connector LINE: -20 dB (3), 600 Ω, unbalanced, phone jack
MIXING INPUT	-20 dB (*3), 10 kΩ, unbalanced, phone jack
ANTENNA	Whip antenna
RECEIVING SENSITIVITY	90 dB or more, Signal to Noise ratio (20 dBμV input, 40 kHz deviation)
SQUELCH SENSITIVITY	16 – 40 dBμV variable
SQUELCH SYSTEM	Using together of noise SQ, carrier SQ and tone SQ
INDICATOR	ANT A/B, Audio (peak), Battery alarm, Channel number
CHANNEL CHECK	Usable frequencies scanning
SIGNAL-TO-NOISE RATIO	104 dB or more (A-weight, unbalanced output)
HARMONIC DISTORTION	1 % or less (typical)
FREQUENCY RESPONSE	100 Hz – 15 kHz, ±3 dB
FINISH	Resin, black
DIMENSIONS	206 (W) × 40.6 (H) × 152.7 (D) mm (8.11 × 1.6″ × 6.01″) (excluding antenna)
WEIGHT	590 g (1.3 lb)

Toa WS-5325H UHF Price in Bangladesh

Price:	৳ 40,000
Brand:	TOA
Model:	WS-5325H
Item:	Toa Wireless Microphone
Contact No:	0185-3330344
Status:	In Stock
Warranty:	One Year

What is the price of a Toa WS-5325H wireless transmitter In Bangladesh?

The latest price of the Toa WS-5325H wireless transmitter in Bangladesh is ৳ 40,000.00. You can buy the Toa WS-5325H wireless transmitter at the best price from our website or visit any of our offices.
